free form biomorphic structures

FEA analysis [2.4]

The polylines are imported into Robot Millennium a Finite Element Analysis software package where component parts, such as ribs and spars, are designed based on stress analysis.

Robot Millennium.

The software package is a graphical user interface which allows structural elements and shapes to be imported for analysis. A mathematical model is created of the structure (FEA) and the solution of simultaneous equations from each element provides the output with regards to deflection, stress etc...

FEA uses a system of points called nodes which make a grid called a mesh. This mesh is programmed to contain the material and structural properties which define how the structure will react to certain loading conditions. Nodes can be assigned at a certain density throughout the material depending on the anticipated stress levels of a particular area. Regions which will receive large amounts of stress usually have a higher node density than those which experience little or no stress.

The mesh acts like a spider web in that from each node, there extends a mesh element to each of the adjacent nodes. This web of vectors is what carries the material properties to the object, creating many elements.

Previous PageHomeNext Page
FEA Analyis Input

Input: Polylines are imported as a *.dxf into Robot.

FEA Analyis Output

Output: Color guide to different sections attributed to bars.
